Made of die-cast aluminium painted with polyester powders, standard colour dark grey. Fixing bracket in galvanized steel, painted with polyester powders in the same colour as the body.
![](https://www.faeber.com/wp-content/uploads/2018/01/banner_fastled2_tunnel.jpg)
![](https://www.faeber.com/wp-content/uploads/2018/01/dettagli_fastled2_tunnel.jpg)
SCREEN
Tempered flat glass, thickness 4mm.
GASKETS
The waterproof quality is ensured by foam silicone gaskets.
LED MODULES
Replaceable 8/24/36 led moduls with secondary PMMA optics; available several photometries: street, simmetric and counterbeam tunnel, asymmetric α 50°, circular 10°/25°/40°/90°. LED light source with high efficiency. Life expectancy of the LEDs > 60000h L70B20.
SUPPLY UNIT
Electrical components mounted inside the body, in the specific compartment. Life expectancy of the ballasts at Tc: 50000 h for the standard solution and 100000 h for the dimmable solution. Supply voltage 220÷240 V 50/60Hz. Insulation class II, upon request available cl. I
FIXING
Available fixing for pole mounting diameter 60mm (Fig.1). Available bracket with clips for cable tray fixing (Fig.2). Available fixing bracket (Fig.3) with possible goniometer (tilt adjustment with steps of 5°).
